Detailed Introduction
| Product model | JAF-FFU4*2 | JAF-FFU4*3 | JAF-FFU4*4 | |||
| Box size（MM） | 1175*575*305 | 1175*875*305 | 1175*1175*305 | |||
| Efficient size（MM） | 1170*570*70 | 1170*870*70 | 1170*1170*70 | |||
| Box material | Aluminium zinc plate / stainless steel / steel paint | Aluminium zinc plate / stainless steel / steel paint | Aluminium zinc plate / stainless steel / steel paint | |||
| The wind speed | 0.35-0.45m/s | 0.35-0.45m/s | 0.35-0.45m/s | |||
| Rated air rate | 900m3/h | 1500m3/h | 2000m3/h | |||
| HEPA efficiency | 99.99%@0.3UM | 99.99%@0.3UM | 99.99%@0.3UM | |||
| Cleanliness | 万级/千级/百级 | 万级/千级/百级 | 万级/千级/百级 | |||
| Power Supply | 单相 220V/50HZ | 单相 220V/50HZ | 单相 220V/50HZ | |||
| Power | 120W | 140W | 160W | |||
| Noise | 48-52dB(A) | 52-54dB(A) | 52-54dB(A) | |||
| Weight | 26KG | 35KG | 50KG | |||
Filt Efficiency:
Product Feature:
Wind machine with direct drive type, centrifugal fan, with a long life, low noise, maintenance free, vibration Xiaoke stepless speed regulation characteristics, service life up to 50000 hours, fan speed, stable performance, high efficiency filter final state of resistance can still be guaranteed constant air flow
The box body and the high-efficiency filteradopts splitdesign, installation, replacement, more convenient
The machine frame is made of high-quality cold-rolled steel or stainless steel spray, anti-corrosion, anti rust, beautiful and generous
The unique air (Archimedes spiral duct) design
The design of stepless speed regulation, speed and stable performance, which still remains unchanged in the air filter resistance of the end state
Most of our products are according to the American federal standard 209E sets rigorous testing, high reliability
] is particularly suitable for assembly or ultra clean production lines, according to needs, the process is arranged for the unit, the multiple cascade connected 100 assembly line
Applications:
The dust-free clean room
The clean room
We manufacture
] semiconductor, LCD display manufacturer and equipped with all sectors of the clean room can be used, especially the cleanliness requirements in 10100100010000100000 five kinds such as and more Taiwan use in the workplace
