Barrier paint mesh glass fiber filtration material

Detailed Introduction

产品型号	规格尺寸	克重	效率	初阻力	耐温度
JAF-049	1M20M60MMT	250G/平方	G3	20Pa	≤150℃
JAF-050	1M20M100MMT	320G/平方	G3	30Pa	≤150℃
特殊尺寸及规格可依客户要求制作。

Filt Efficiency:

Paint fog felt also called: paint mesh, cotton, glass fiber fluffy felt, fiberglass mesh, paint mesh, paint resistance

Product Feature:

The long glass fiber to non fabric style, gradually close type structure is made and large ventilation quantity and the air resistance is small, the paint mist l catch dust efficiency is good, can be used for a long time. The characteristic of the gradual dense structure with high elasticity and low pressure loss. With high elasticity and low pressure, some wind speed, air current and dust can not compress, deformation and collapse, can still maintain high efficiency and can increase the service life of the filter.. Gradually layer, the density and type of filter structure, according to the size of dust, are blocked at different density levels more effectively accommodate more dust, and low resistance, depth type filtration method. Into the wind surface is white, the wind is green. Flame retardant, high temperature 170 degrees celsius. Flame retardant point in line with German industrial standard F1 DIN4102. Moisture resistance, can reach 100%

Applications:

Air intake of general air-conditioning system.

* dry painting spray paint spray station, automotive paint room exhaust system.

Treatment of industrial waste gas and processing dust collection.
